Λεπτομέρειες
.100 tests per hour, up to 300 tests per hour with ISE (K, Na, Cl, Li)
. 24-hour refrigeration for reagent tray
. Flexible reagent/sample tray
. Independent mixing stirrer
. Robust and user-friendly operation software
. Best cost-efficiency
. Pre-dilution and post-dilution for sample
. Bi-directional LIS interface
Chemistry Reagents
Hepatic
Alanine Aminotransferase (ALT) Aspartate Aminotransferase (AST) Alkaline Phosphatase (ALP) γ-GlutamylTransferase (γ-GT) Direct Bilirubin (D-Bil) DSA Method Direct Bilirubin (D-Bil)VOX Method Total Bilirubin (T-Bil) DSA Method Total Bilirubin (T-Bil)VOX Method Total Protein (TP) Albumin (ALB) Total Bile Acids (TBA) Prealbumin (PA) Adenosine deaminase (ADA) * α-L-fucosidase (AFU) * 5'-nucleotidase (5'-NT) *
Renal Urea
(UREA) Creatinine (CREA) Modified JafféMethod Creatinine (CREA)Sarcosine OxidaseMethod Uric Acid (UA) Microalbumin* β2-Microglobulin (β2-MG) * Cystatin C (CysC) *
Cardiac
Creatine Kinase (CK) Creatine Kinase-MB (CK-MB) Lactate Dehydrogenase (LDH) α-Hydroxybutyrate Dehydrogenase(α-HBDH) Myoglobin*
Ferrum Iron (Fe) Ferritin (FER) * Transferrin (TRF) * Total iron binding capacity / unsaturated iron Binding capacity (TIBC/UIBC) *
Lipids
Total Cholesterol (TC) Triglycerides (TG) HDL-Cholesterol (HDL-C) LDL-Cholesterol (LDL-C) Apolipoprotein A1 (ApoA1) Apolipoprotein B (ApoB) Lipoportein(a) [LP(a)]
Pancreatitis
α-Amylase (α-AMY) Lipase (LIP)
Diabetes
Glucose (Glu) GOD-POD Method Glucose (Glu) HK Meth Fructosamine (FUN)
Inorganic ions
Calcium (Ca) Magnesium (Mg) Phosphate Inorganic (P)
Rheumatism
High sensitivity C-reactive protein (hs-CRP) * Rheumatoid Factor (RF) Antibodies Against Streptolysin O (ASO)
Immune
Immunoglobulin A (IgA) Immunoglobulin G (IgG) Immunoglobulin M (IgM) Immunoglobulin E (IgE) * Complement C3 (C3) Complement C4 (C4) C-Reactive Protein (CRP)
Others
Glucose-6-phosphate dehydrogenase (G6PD) * D-dimer* Angiotensin converting enzyme (ACE) * Retinol binding protein (RBP) * D3-hydroxybutyric acid (D3-HB) *
* Coming soon
Επιπρόσθετες Πληροφορίες
| Tests per box | 1 |
|---|---|
| Strips | Μη Διαθέσιμο |
| Customer Groups Price | Όχι |
| Intended use | End-point, fixed-time, kinetic, optional ISE Single/dual reagent chemistries, monochromatic/bichromatic linear/non-linear multipoint calibration |
| Advantages | Technical Specifications: System Function:Automatic, discrete, random access, STAT sample priority Throughput:Up to 100 tests/hour (without ISE), up to 300 tests/hour with ISE (3 ions) Measuring principles:Absorbance photometry, turbidimetry, Ion Selective Electrode technology Methodology: End-point, fixed-time, kinetic, optional ISE Single/dual reagent chemistries, monochromatic/bichromatic linear/non-linear multipoint calibration Programming:Open system with user defined profiles and calculations
Reagent/Sample Handling: Reagent/Sample tray:Up to 33 positions for sample, up to 35 positions for reagent; 24 hour non-stop refrigerated compartment (4~15˚C) Reagent volume:R1: 180~450μl, step by 1μl R2: 30~250μl, step by 1μl Sample volume: 3~45μl, step by 0.5μl Reagent/Sample probe:Liquid level detection, collision protection and inventory checking Probe cleaning:Automatic washing both interior and exterior Carry-over < 0.1% Automatic sample dilution:Pre-dilution and post-dilution dilution ratio up to 1: 150 Dilution vessel:Disposable cuvette ISE Module (optional):Measure parameter: K+, Na+, Cl− Reaction System: Reaction rotor:Rotating tray, containing 40 cuvettes Cuvette: Optical length 5mm Reaction volume: 180~500μl Reaction temperature:37±0.1˚C Mixing system: Independent mixing bar Optical System: Light Source: Halogen-tungsten lamp Wavelength: 340nm, 405nm, 450nm, 510nm, 546nm, 578nm, 630nm, 670nm Linear range: 0~3.5Abs Control and Calibration: Calibration mode: Linear (one-point, two-point and multi-point), Logit-Log 4P, Logit-Log 5P, Spline, Exponential, Polynomial, Parabola Control rules: Westgard multi-rule, Cumulative sum check, Twin plot Operation Unit: Operation system: Windows® XP Professional/Home SP2, Windows® 7 or above Windows® VISTA Home/Business Interface: RS-232 Working Conditions: Power Supply: AC 200~240V, 50/60Hz, 800W or AC 100~130V, 50/60Hz, 800W Temperature: 15~30˚C Humidity: 35~85% Water consumption: 2.5L/hour Dimension: Bench top: 690mm(W)x570 mm(D)x595 mm(H) Weight: 75 Kg |
| Reading time | Όχι |
